Duratron® T4203 PAI

Amarelo - duratron

The Duratron® T4203 PAI offers the best toughness and impact resistance of all Duratron® PAI grades. The Duratron® PAI extruded is very popular for precision parts in high-tech equipment. In addition, its good electrical insulation capability offers numerous possibilities in the field of electrical components. Duratron® T4503 PAI compression molded, has a composition similar to Duratron® T4203 PAI and is selected when larger shapes are required.

The Duratron® T4203 PAI is especially used in electrical connectors and can chucks.

Set up your product


Format

Chemical

Resistance

Electrical

Insulation

Wear

resistance

sliding

properties

impact

resistance

+250ºC / -50ºC

temperature range

MAIN CHARACTERISTICS



- High maximum service air temperature (250 ° C continuous)

- Excellent retention of mechanical strength, stiffness and creep resistance over a wide temperature range

- Excellent dimensional stability up to 260 ° C

- Very good resistance to UV rays

- Exceptional resistance against high energy radiation (gamma rays and X-rays)

-Independent low flammability

ApPLICATIONS


- Electrical and insulating connectors

- Structural components (such as connections and sealing rings)

- Wear applications involving impact load and abrasive wear

- Standard Matrix of Metal Parts Shaped (T4503)

- Cages for bearings
